■ TG Series（7S〜30S）/Single Phase

MODEL				TG-7S		TG-12S		TG-14S		TG-21S		TG-30S
Generator	Frequency (Hz)			50	60	50	60	50	60	50	60	50	60
	Out put (KW)	Stand-by		6.5	7.3	9.8	11.7	11.5	14.5	16.4	21.0	26.1	30.0
		Prime		5.5	6.6	8.8	10.6	10.8	13.5	15.6	20.0	23.8	27.3
	Rated speed (min-1)			1500	1800	1500	1800	1500	1800	1500	1800	1500	1800
	Voltage (V)			220、230、240（110/220、120/240） Please instruct the use voltage.
	Bearing			Single bearing
	Voltage regulation			AVR
MODEL				D1005B		V1505B		D1703B		V2203B		V3300B
Engine	Continuous rating out put		PS	9.8	11.8	15.1	18.2	18.5	22.4	25.0	32.2	36.8	43.9
			KW	7.2	8.7	11.1	13.4	13.6	16.5	18.4	23.7	27.0	32.3
	Fuel consumption ℓ/h			2.2	2.6	3.3	4.0	3.9	4.8	5.4	6.9	7.7	9.1
	Fuel tank capacity ℓ			40								60
	Dry Weight(kg)		BS	390		510		570		610		875
			B	350		450		490		570		785
			PC	300		430		485		545		695
			A1	280		400		410		465		640

■ TG Series（10T〜47T）/Three Phase

MODEL				TG-10T		TG-15T		TG-19T		TG-28T		TG-40T		TG-47T
Generator	Frequency (Hz)			50	60	50	60	50	60	50	60	50	60	50	60
	Out put (KW)	Stand-by		8.5	9.5	13.0	15.5	15.0	18.5	22.0	27.5	33.5	39.0	39.2	47.5
		Prime		7.2	8.7	11.5	14.0	13.5	17.0	20.0	25.0	30.5	35.0	35.6	43.1
	Rated speed (min-1)			1500	1800	1500	1800	1500	1800	1500	1800	1500	1800	1500	1800
	Voltage (V)			AC200〜480V Please instruct the use voltage.
	Bearing			Single bearing
	Voltage regulation			AVR
MODEL				D1005B		V1505		D1703B		V2203B		V3300B		V3300TB
Engine	Continuous rating out put		PS	9.8	11.8	15.1	18.2	18.5	22.4	25.0	32.2	36.4	43.9	43.0	52.9
			KW	7.2	8.7	11.1	13.4	13.6	16.5	18.4	23.7	26.8	32.3	31.6	38.9
	Fuel consumption ℓ/h			2.2	2.6	3.3	4.0	3.9	4.8	5.4	6.9	7.7	9.1	8.9	10.8
	Fuel tank capacity ℓ			40								60
	Dry Weight (kg)		BS	390		510		570		610		875		900
			B	350		450		490		570		785		810
			PC	300		430		485		545		695		740
			A1	280		400		410		465		640		670
